mNVR S260

Storage
m.2 SATA 120 GB, MicroSD 16Gb-512Gb
Wireless modem
2G GSM / 3G UMTS / 4G LTE
LTE Cat 4, ⤒ 50Mbit ⤓ 150Mbit
GNSS
GPS / GLONASS / Galileo / BEIDOU
Wi-Fi module
802.11bgn : 2.4Ghz, 802.11ac : 5Ghz
Interfaces
BITREK CONNECT(CAN), Ethernet, Wi-Fi, RS485

Device configuration includes:

  • mNVR S250 with 2G/3G/4G Quectel modem on board and ARM-based processor;
  • Precise GPS receiver;
  • 4 pcs of an IP camera (automotive mobile camera Bitrek);
  • m.2 SATA 120 GB;
  • 128b VPN encryption (FTP inside VPN tunnel);
  • Wi-Fi 2.4GHz /5GHz;
  • Built-in CANbus;
  • 2 external 2G/3G/4G antennas;
  • 1 external GPS antenna;
  • 1 Wi-Fi antenna,
  • Solid automotive metal case.

NVR has eight operational modes:
– Photo;
– Non-stop video;
– Non-stop video recording, with adjusted pauses between recordings;
– Video with fixed duration;
– Video recording that starts/stops by the event (one-shot video);
– Photo recording that starts/stops by the event;
– Time-lapse photo. The device takes pictures at a specified interval, and when an event happens – it creates a collage of shots before the event.
– Video with the event in the center. NVR creates a video, including what was happening BEFORE the event, the EVENT itself, and AFTER the event.

Our NVR sends to the server location and photo/or link to photo or video via IPS protocol in regular operation. All information can be stored in internal memory and uploaded over the Wi-Fi point by the end of the day/week (garage etc.).

Streaming video:

Live broadcasts via RTSP protocol.
Live broadcasts via RTMP protocol.
Live broadcasts via RTMP Publisher protocol.
Live streaming via HLS protocol.
Live streaming via MPEG DASH protocol.

Event triggers (control protocols):

  • Web interface;
  • Bitrek CAN interface (external sensors generate events);
  • IPS protocol;
  • Web API.
Wireless capabilities
Method
2G/3G/4G
Wi-Fi
2.4GHz /5GHz
GPS / GSM antennas
3 pcs external
Power
Current consumption
12V / 24V
Power consumption
220mAh
Expandability
up to 100 external sensors per vehicle
Interfaces
USB, CAN, RJ 45, RS 232, RS 485, digital input, digital output, analog input, analog output, 1-Wire
Internal storage
m.2 SATA 120 GB, MicroSD 16Gb-512Gb (optional)
Cameras
Camera type
IP
Camera connector type
RJ 45, 4 ports 10/100 mb
Camera power supply
PoE
Data transfer protocol
IPS, FTP inside VPN tunnel
Configuration type
Web interface
Camera protocol format
RTSP, codec X264, X265
Movement sensor
3 Axis G-sensor (accelerometer)
Physical dimensions
Case
200х120х75 mm / 7.87x4.73x2.95inch
Case material
Metal
Weight
500 gr / 1,10 lb
Data sheet

Download file

Bitrek NVR on Wialon

Download file

ISO certification for production lines

Download file

Web interface admin panel
