Bitrek’s digital thermometr
Bitrek’s digital temperature sensor.
This sensor has standard rates and combines an attractive price with precise measurements and internal memory.
For more information, pls check the product description.
Go to comparison
Sample order
Device operational logic: the digital code delivered from the thermometer is a direct code of the measured temperature value and does not need additional conversions.
The range of measured temperatures is from -55 ° C to + 125 ° C. The absolute conversion error is less than 0.5 ° C in the controlled temperature range of -10 ° C to + 85 ° C. The maximum time for a full 12-bit conversion is ~ 750ms (at a resolution of 12 bits).
The internal memory of the thermometer provides setting up temperature limits (the upper and lower). In addition, the microcircuit contains a built-in logic mechanism for priority signaling in the line about the fact that the temperature has exceeded one of the selected thresholds. The device’s 1-Wire interface node allows connecting 5 pcs of such sensors to a single tracker.
The thermometer can operate without an external power source, only due to the parasitic power supply of a single-wire line. The device is powered through a separate external output with a voltage from 3.0V to 5.5V.
To define a full list of possible parameters and application scenarios for your vehicle pls contact us directly.
Model name | DS18B20 |
Case | TO-92 |
Bits | 9-12 b |
Conversion time | 750nS(max) |
Supply voltage | 6V / 40V |
Comsumption | 1 mAh |
Measurement accuracy ± 0.5% (in the temperature range) | -10 ….+85°С |
Measured temperature range | -55 ° C .... + 125 ° C |
Supply voltage for measurement accuracy ± 0.5% | 3,0-5,5V |
Digital interfaces | 1-Wire |
Cable | 1.5 m |
